| Tyre Specification | Pattern Depth | Standard Rim | Dimension/mm | Load capacity at different speeds/kg | ||||
|---|---|---|---|---|---|---|---|---|
| Outer Diameter | Section Width | Counterbalanced Forklift Trucks | Industrial Vehicle | |||||
| 10km/h Driving Wheel | 25km/h Driving Wheel | 10km/h | 25km/h | |||||
| 300-15/8.0 | 33.0mm | 8.0-15 | 838 | 300 | 6895 | 5850 | 5310 | 4500 |
| 28X9-15/7.0 | 29.0mm | 7.0-15 | 706 | 225 | 4060 | 3445 | 3125 | 2650 |
| 21X8-9/6.00 | 22.5mm | 6.00E-9 | 535 | 207 | 2890 | 2645 | 2230 | 1890 |
| 18X7-8/4.33R | 20.0mm | 4.33R-8 | 457 | 170 | 2430 | 2060 | 1870 | 1585 |
| 16X6-8/4.33 | 15.5mm | 4.33R-28 | 162 | 418 | 1545 | 1190 | 1185 | 1005 |
| 9.00-20/7.0 | 37.5mm | 7.0-20 | 1038 | 259 | 6365 | 5400 | 4905 | 4500 |
| 8.25-15/6.50 | 35.0mm | 6.50-15 | 847 | 236 | 5085 | 4310 | 3910 | 3315 |
| 7.00-12/5.00S | 29.0mm | 5.00S-12 | 683 | 192 | 3105 | 2635 | 2390 | 2025 |
| 6.50-10/5.00 | 25.0mm | 5.00F-10 | 597 | 178 | 2715 | 2310 | 2095 | 1775 |
| 6.00-9/4.00 | 23.3mm | 4.00E-09 | 545 | 160 | 1975 | 1675 | 1520 | 1290 |
