Features

Outstanding resistance to uneven wear.

Long mileage.

The width of tread running surface and the density of pattern are increased to promote driving distance and operation efficiency.

Finite element optimization tire crown design and rugged shoulder pattern reduce uneven wear and prolong service life.

Complex angle design of grooves protects carcass, avoids stone pinching, improves puncture-resistant performance.

Scope of application

Regional – Trailer Axle

Features

Tire Size	Ply Rating	Load Index	Speed Symbol	Overall Diameter (mm)	Section Width (mm)	Tread Arc Width (mm)	Tread Depth (mm)	Rim	Single Max L/P(kg/kPa)	Dual Max L/P(kg/kPa)
12R22.5	16PR	150/147	L	1082	298	230	15.5	9.00	3350/830	3075/830
12R22.5	18PR	152/149	L	1082	298	230	15.5	9.00	3550/930	3250/930

Tire Size

Ply Rating

Load Index

Speed Symbol

Overall Diameter
(mm)

Section Width
(mm)

Tread Arc Width
(mm)

Tread Depth
(mm)

Rim

Single Max L/P(kg/kPa)

Dual Max L/P(kg/kPa)

Fuel Efficiency (EU)

Wet Grip (EU)

Noise Level (EU)

12R22.5

16PR

150/147

1082

298

230

15.5

9.00

3350/830

3075/830

12R22.5

18PR

152/149

1082

298

230

15.5

9.00

3550/930

3250/930
